PRODUCT > Drie-d
Drie-d
DRIE-D
Modern Engineering Pty Ltd
We are a special company that deals with bearing which is applied as a product of the most proper conditions. We make such bearing by mixing high-functional plastic materials that are used in any fields of industry such as plants and shipbuilding.
For further information visit : www.drie-d.com
| Properties | Unit | D Glide P |
D Glide F |
D Glide FT |
D Glide FS |
D Glide FC |
D Glide U |
|---|---|---|---|---|---|---|---|
| Compressive strength |
(Mpa) | 325 | 350 | 300 | 350 | 350 | 390 |
| Shear strength |
(Mpa) | 95 | 105 | 95 | 105 | 105 | 110 |
| Stiffness under com. |
(Mpa) | 2000 | 1600 | 1600 | 3000-6000 | 1600 | 2200 |
| Density | (103Kg/㎥) | 1.25 | 1.35 | 1.35 | 1.35 | 1.35 | 1.4 |
| Max. temperature |
℃ | 130 | 150 | 150 | 150 | 150 | 250 |
| Min. temperature |
℃ | ←200 | ←200 | ←200 | ←200 | ←200 | ←200 |
D-glide FC
D-glide FS
D-glide F
D-glide FT
D-glide FC
